| 型号名称 |
能力 螺丝 直径 (参考) mm |
转矩范围N.m | 无负荷回转速度(约)rpm |
全长 无套筒 (约)mm |
重量 无套筒 (约)kg |
从轴心 到侧面 (约)mm |
刀头 插入 尺寸 mm |
软管 接头 螺纹 |
推荐 软管 内径 mm |
空气 耗气量 |
噪音值 dB(A) |
振动 加速度 (3-axes) m/S2 |
产品 代码 |
||||
| 0.4MPa | 0.5MPa | 0.6MPa | 0.4MPa | 0.5MPa | 0.6MPa | ||||||||||||
| U-50EC | 6 | 3.5-8.0 | 4.0-10.0 | 5.0-11.0 | 1900 | 2000 | 2100 | 195 | 1.50 | 24.0 | 9.5Sq | RC¼ | 9.5 | 0.25 | 72 | 2.8 | 17701 |
| U-60EC | 6 | 8.0-20.0 | 10.0-25.0 | 15.0-30.0 | 1700 | 1800 | 1900 | 193 | 1.57 | 27.0 | 9.5Sq | RC¼ | 9.5 | 0.35 | 75 | 3.6 | 19351 |
| UX-80EC | 8 | 15.0-35.0 | 15.0-40.0 | 20.0-45.0 | 1600 | 1700 | 1800 | 196 | 1.80 | 30.0 | 9.5Sq | RC¼ | 9.5 | 0.45 | 77 | 5.0 | 18101 |
| U-100EC | 10 | 35.0-65.0 | 40.0-70.0 | 50.0-80.0 | 1400 | 1500 | 1600 | 233 | 2.80 | 33.0 | 12.7Sq | RC¼ | 9.5 | 0.65 | 78 | 9.8 | 19371 |
| UX-120EC | 12 | 65.0-120.0 | - | - | 900 | - | - | 255 | 3.90 | 36.0 | 12.7Sq | RC¼ | 9.5 | 0.80 | 80 | 10.8 | 18271 |
| UX-130EC | 12 | 65.0-120.0 | 80.0-150.0 | 90.0-170.0 | 950 | 1050 | 1250 | 273 | 4.70 | 40.0 | 12.7Sq | RC¼ | 9.5 | 1.00 | 80 | 16.7 | 18291 |
| U-50SEC | 6 | 3.5-8.0 | 4.0-10.0 | 5.0-11.0 | 1900 | 2000 | 2100 | 280 | 1.55 | 21.0 | 9.5Sq | RC¼ | 9.5 | 0.22 | 72 | 27.0 | 16931 |
| U-60SEC | 6 | 8.0-15.0 | 10.0-20.0 | 15.0-25.0 | 1700 | 1800 | 1900 | 305 | 2.00 | 27.0 | 9.5Sq | RC¼ | 9.5 | 0.35 | 75 | 37.0 | 19251 |
| U-50DEC | 6 | 3.5-8.0 | 4.0-10.0 | 5.0-11.0 | 1900 | 2000 | 2100 | 201 | 1.50 | 24.0 | 6.35Hex | RC¼ | 9.5 | 0.25 | 72 | 2.9 | 17721 |
| U-60DEC | 6 | 8.0-20.0 | 10.0-25.0 | 15.0-30.0 | 1700 | 1800 | 1900 | 198 | 1.57 | 27.0 | 6.35Hex | RC¼ | 9.5 | 0.35 | 75 | 3.8 | 19261 |
| U-50SDEC | 6 | 3.5-8.0 | 4.0-10.0 | 5.0-11.0 | 1900 | 2000 | 2100 | 288 | 1.55 | 21.0 | 6.35Hex | RC¼ | 9.5 | 0.22 | 72 | 28.0 | 16941 |
