| 型号名称 |
能力螺丝直径 (参考)mm |
转矩范围 N·m |
无负荷运转速度 (约)rpm |
全长无套筒/刀头 (约)mm |
重量无套筒/刀头 (约)kg |
从轴心到侧面 (约)mm |
套筒/刀头插入尺寸 mm |
噪声值 db(A) |
产品代码 |
| UEP-50MC | 5 | 5.0-10.0 | 2000 | 200.0 | 2.07 | 28.0 | 9.5Sq | 59.0 | 13731 |
| UEP-60MC | 6 | 10.0-25.0 | 2000 | 222.5 | 2.26 | 28.0 | 9.5Sq | 68.0 | 13751 |
| UEP-70MC | 8 | 25.0-40.0 | 2000 | 237.5 | 2.48 | 31.0 | 9.5Sq | 73.0 | 13771 |
| UEP-80MC | 8-10 | 30.0-60.0 | 2000 | 237.5 | 3.01 | 36.5 | 12.7Sq | 71.0 | 13781 |
| UEP-100MC | 10-12 | 60.0-120.0 | 2000 | 276.0 | 4.16 | 36.5 | 12.7Sq | 75.0 | 13791 |
| UEP-50DMC | 5 | 5.0-10.0 | 2000 | 199.5 | 2.07 | 28.0 | 6.35Hex | 59.0 | 13741 |
| UEP-60DMC | 6 | 10.0-25.0 | 2000 | 222.0 | 2.26 | 28.0 | 6.35Hex | 68.0 | 13761 |
