| 型号 |
工作能力螺栓尺寸 (mm) |
转矩范围 N·m |
无负荷 回转速度 rpm |
全长 mm |
重量 kg |
套筒 插入尺寸 (mm) |
软管接头 螺纹 |
推荐的 软管内径 mm |
空气耗气量 m3/min |
噪声值 dB(A) |
产品代码 |
| UAN-611R-60C | 6 | 6.5-12.0 | 620 | 383 | 1.60 | 9.5Sq | RC¼ | 9.5 | 0.60 | 80 | 26891 |
| UAN-611R-50C | 6-8 | 8.5-15.0 | 470 | 373 | 1.60 | 9.5Sq | RC¼ | 9.5 | 0.60 | 80 | 26881 |
| UAN-611R-40C | 6-8 | 10.0-18.0 | 400 | 373 | 1.60 | 9.5Sq | RC¼ | 9.5 | 0.60 | 80 | 26871 |
| UAN-611R-30C | 8 | 13.0-25.0 | 270 | 373 | 1.60 | 9.5Sq | RC¼ | 9.5 | 0.60 | 80 | 26861 |
| UAN-701R-60C | 8 | 20.0-31.0 | 600 | 445 | 2.40 | 9.5Sq | RC¼ | 9.5 | 0.90 | 85 | 26971 |
| UAN-701R-40C | 8-10 | 28.0-45.0 | 400 | 445 | 2.40 | 9.5Sq | RC¼ | 9.5 | 0.90 | 85 | 26961 |
| UAN-701R-30C | 10-12 | 37.0-60.0 | 300 | 445 | 2.40 | 12.7Sq | RC¼ | 9.5 | 0.90 | 85 | 26951 |
