| 产品编号 | 安装类型 | 泵压力比 |
60cpm时的流体 gpm(lpm) |
最大工作压力 psi (MPa, bar) |
最大进气压力 psi (MPa, bar) |
每循环流量 | 进气口尺寸 | 流入口尺寸 | 流体出口尺寸 |
|
247549 247550 |
车载 壁载 |
12:1 | 8.7 (33.0) | 1250(8.6, 86) | 100psi (0.7, 7) | 18.6 oz (550 cc) | 3/4” npt(f) | 1 in | 3/8 in |
|
247551 247552 |
车载 壁载 |
23:1 | 9.2 (34.7) | 2275 (15.7, 157) | 100psi (0.7, 7) | 19.6 oz (580 cc | 3/4” npt(f) | 1 in | 3/8 in |
|
247553 247554 |
车载 壁载 |
30:1 | 6.8 (25.9) | 3065 (21.1, 211) | 100psi (0.7, 7) | 14.5 oz (430 cc | 3/4” npt(f) | 1 in | 3/8 in |
|
258664 258665 |
车载 壁载 |
45:1 | 4.6 (17.4) | 4500 (31.0, 310) | 100psi (0.7, 7) | 9.8 oz (290 cc) | 3/4” npt(f) | 1 in | 3/8 in |
| 206515 | 桶装 | 10:1 | 3.0 (11.4) | 1800 (12.5, 125,) | 180psi(1.2, 12.5) | 6.4 oz (189 cc) | 1/2” npt(f) | 1/2 in | 3/4 in |
每台泵含二个出口及包含喷嘴
不锈钢喷嘴选型表
| 编号 | 喷嘴货号 | 喷嘴口尺寸 |
40 psi 情况下喷射扇面角度 (3 bar, 0.03 MPa) 1000 psi 情况下的流量 |
1000 psi 情况下的流量 (68.9 bar, 6.89 MPa) |
| 805534 | 40020 | 0.020 in (0.51 mm) | 40º | 1.00 gpm (3.78 lpm) |
| 805538 | 40030 | 0.030 in (0.76 mm) | 40º | 1.50 gpm (5.68 lpm) |
| 805542 | 40035 | 0.035 in (0.89 mm) | 40º | 1.75 gpm (6.62 lpm |
| 805549 | 25045 | 0.045 in (1.14 mm) | 25º | 2.25 gpm (8.52 lpm |
| 805561 | 25060 | 0.060 in (1.52 mm) | 25º | 3.00 gpm (11.36 lpm) |
| 805562 | 40060 | 0.060 in (1.52 mm) | 40º | 3.00 gpm (11.36 lpm) |
| 805566 | 40065 | 0.065 in (1.65 mm) | 40º | 3.25 gpm (12.30 lpm) |
| 805569 | 25070 | 0.070 in (1.78 mm) | 25º | 3.50 gpm (13.25 lpm) |
| 805458 | 40075 | 0.075 in (1.91 mm) | 40º | 3.75 gpm (14.20 lpm) |
| 805575 | 00080 | 0.080 in (2.03 mm) | 0º | 4.00 gpm (15.14 lpm) |
| 805587 | 00100 | 0.100 in (2.54 mm) | 0º | 5.00 gpm (18.93 lpm) |
